Invisibility cloaks, long a myth of science fiction, have advanced technologically to the point where they are now being implemented in real-life applications.
Image Credit: luchschenF/Shutterstock.com
In the natural world, light beams can occasionally be twisted as they travel through layers of varyingly heated air. In 2006, Sir John Pendry unveiled a ground-breaking concept demonstrating how light could bend around an object encased in a metamaterial shell.1 Since then, scientists have developed a wide range of electromagnetic wave "invisibility cloaks."
Metamaterials are artificially constructed materials used to shape and regulate electromagnetic wave propagation.
The uniqueness of Pendry's concept lies in its ability to manipulate matter so that light within metamaterials follows curved trajectories. In the field of transformational optics, a variety of mirages can be envisioned by creating heterogeneous anisotropic media that warp the dimensions of space.
Invisibility Cloaking: Fundamental Principles and Current Technology
The primary goal of cloaking is to conceal an object from identification by any detecting device. This becomes possible if the electromagnetic field can bend around the object intended to be concealed, allowing an electromagnetic wave incident upon it to exit the cloak without being reflected or scattered.
By applying a conformal coordinate transformation to Maxwell's equations, a spatially distributed set of constitutive parameters that describe the cloak is obtained. This process is known as transformation optics.
For example, constructing an invisibility cloak involves expanding a point that compresses the surrounding area, creating a metamaterial shell with concentric layers that possess different refractive indices.
However, transformational optics extends beyond this; it can also be used to alter the trajectories of other wave types, including mechanical, water, and sound waves, through the warping of space.
Mathematical formulations show that different wave mediums conform differently in reality. For instance, in contrast to Maxwell's equations of electromagnetism, which are transformation invariant, the Navier equations governing the properties of mechanical waves do not behave well under space transformations, resulting in mechanical metamaterials with highly unusual properties.
This variety in response underscores the advanced state of transformational physics, exemplified by the sophisticated design, creation, and experimental verification of invisibility cloaks and carpets.2
Various invisibility techniques have been explored and published over the years, each offering unique advantages and limitations tailored to specific application circumstances. Examples of these schemes include zero-refractive-index invisible channels and ultrathin metasurface cloaks. Metasurface cloaks, in particular, have gained rapid popularity in both academic and industrial circles due to their low insertion loss, minimal thickness, and ease of access.
Challenges and Limitations of Existing Invisibility Approaches
Existing invisibility cloaks share a common limitation: they are designed to operate in a single direction, with prior-defined electromagnetic illumination, and against a stationary background.3
In practice, transitioning to different environments, such as air, sea, or deserts, introduces unique scattering properties that weaken the well-defined cloaking effect. Incorporating real-world features would mark the beginning of intelligent cloaking that adapts to dynamic, nondeterministic surrounding landscapes.
However, achieving this objective presents a range of challenges, from developing sophisticated algorithms and applying fundamental physics principles to creating an all-in-one system.
Revolutionizing Cloaking with Invisibility Drones
A novel cloaking concept using an autonomous drone platform with microwave-thin, customizable metasurfaces has been demonstrated to overcome current one-dimensional limitations.
This innovative aeroamphibious cloak can neutralize external inputs and adapt to various situations via probabilistic reasoning. By introducing spatiotemporal modulation into the metasurfaces, a large number of equivalent reflection states spanning the whole phase diagram is created. This provides a basis for integrating novel capabilities and adaptable cloaking modalities at a physical level.
To automate the invisible drone, a generation-elimination network, termed stochastic-evolution learning, is employed, quickly outputting control commands for the spatiotemporal metasurfaces.
In this study, a conical detecting region is freely flown by an all-in-one invisible drone with almost no backscattering, giving the impression that nothing is there.3
The drone is benchmarked against an amphibious background, blending into either a pure background or randomly generated user-defined illusive patterns. This research opens up a new class of sea-land-air intelligent cloaks and encourages the commercialization of numerous previously unattainable ideas, including distributed metasurfaces and inter-satellite communication.
The Diverse Applications of Invisibility Cloaks
As a result of their unique properties, various industries stand to gain significantly from invisibility cloak technology.
In the military and surveillance sectors, the ability to conceal, from specific angles, the locations of heavy artillery, ground forces, or even entire structures offers a considerable strategic advantage. Extending from military applications, invisibility cloaks have potential in telecommunication, including the study of miniature satellites equipped with cloaking capabilities.
With the unique capabilities provided by invisibility cloaks, various industries stand to gain significantly from this technology.
In the military and surveillance sectors, the ability to conceal, from specific viewpoints, the positions of heavy artillery, ground forces, or even entire structures offers a considerable strategic advantage. Beyond military applications, invisibility cloaks hold promise for telecommunications, including the study of miniature satellites equipped with cloaking capabilities.
The principles behind invisibility cloaks could also enhance applications already benefiting from drone technology. For instance, drones equipped with flyby gas emission sensors monitor pollutant gases. In the aftermath of natural disasters, and during humanitarian relief efforts, drones are crucial in reaching inaccessible areas. Invisibility technology could allow drones to gather data and deliver aid in disaster zones discreetly, improving mission effectiveness by reducing disturbances and ensuring uninterrupted operations.
Imaging cameras fitted in drones are extensively used to monitor agricultural crops and to detect unwanted plant and algae growth in water bodies, contributing to wildlife protection. Looking forward, invisibility cloaks could significantly impact wildlife conservation by shielding animals from external threats, and they may find applications in public safety and green energy solutions.
Vision for the Future: Intelligent Cloaks and Metasurfaces
Intelligent metasurfaces and intelligent cloaks are entering a new era of technical creativity. Efforts to automate meta-devices, capture latent physics, and streamline photonics design are underway to accomplish this goal.
Recent breakthroughs pave the way for a redesigned intelligent cloak paradigm, sparking a wave of new intelligent meta-device classes that use spatiotemporally controlled architectures for sophisticated on-demand functionality.
Over time, sharing similar experiences through transfer techniques could enable the conveyance of information in ambiguous situations, and the latest advances in deep learning significantly increase the robustness in cases characterized by scarce data and non-applicable models.
More from AZoOptics: Using Metamaterials to Manipulate Light
References and Further Reading
- Guenneau, SJ. (2015) The physics of invisibility. [Online] The Royal Society. Available at: https://royalsociety.org/blog/2015/08/the-physics-of-invisibility/#:~:text=For%20instance%2C%20an%20invisibility%20cloak,layers%20of%20varying%20refractive%20index
- Kadic, M., Bückmann, T., Schittny, R., Wegener, M. (2015) Experiments on cloaking in optics, thermodynamics, and mechanics. Phil. Trans. R. Soc. A. doi.org/10.1098/rsta.2014.0357
- Qian, C., Jia, Y., Wang, Z., Chen, J., Lin, P., Zhu, X., Li, E., Chen, H. (2024). Autonomous aeroamphibious invisibility cloak with stochastic-evolution learning. Adv. Photon. doi.org/10.1117/1.AP.6.1.016001
