A recent study published in Advanced Optical Materials explored the potential of a polymer of intrinsic microporosity (PIM-1) as a light absorber in luminescent solar concentrators (LSCs). The researchers investigated how combining PIM-1 with the red-emitting dye Lumogen F Red 305 (LR305) could enhance solar energy efficiency and cost-effectiveness while addressing environmental challenges.
Image Credit: cpaulfell/Shutterstock.com
Developments in Solar Energy Technology
The global energy crisis and environmental concerns have led to increased interest in renewable energy sources, particularly solar power. LSCs capture sunlight and direct it to photovoltaic (PV) cells, reducing reliance on costly solar panels. By absorbing sunlight and re-emitting it at longer wavelengths, LSCs efficiently channel energy to their edges, making them suitable for use in windows and building facades.
Traditional LSCs use organic dyes and polymers, but challenges such as non-radiative reabsorption and low luminescence efficiency have limited their effectiveness. PIM-1 offers strong visible-light absorption and high fluorescence quantum yield, making it a promising alternative.
Investigating PIM-1 in LSCs
Researchers synthesized PIM-1 using established methods and characterized its structure through gel permeation chromatography and nuclear magnetic resonance. The polymer had a surface area of 777 m²/g, confirming its microporous nature. The study evaluated PIM-1 as an energy donor in a Förster Resonance Energy Transfer (FRET) system, pairing it with LR305 as the energy acceptor.
To analyze optical properties, the team prepared thin films of PIM-1 with different LR305 concentrations and conducted solid-state fluorescence quenching experiments. Time-resolved fluorescence decay measurements provided insights into energy transfer dynamics. The quantum yield and optical properties of the LSC prototypes were assessed using integrating spheres and spectroscopic techniques.
Key Findings: Impact of PIM-1
PIM-1 exhibited a strong absorbance peak at around 420 nm, with a moderate Stokes shift of about 70 nm. This reduced reabsorption losses since PIM-1’s absorption band did not overlap with the emission band of LR305, which peaked at 605 nm. The addition of LR305 significantly increased the fluorescence quantum yield of the PIM-1 matrix, reaching a maximum of 51.1 % with just 1.0 wt.% dye.
The prototype LSC achieved an internal efficiency of 25 % and an external efficiency of 12.6 %, comparable to other FRET-based LSCs. Additionally, 71 % of emitted photons exited through the edges, indicating effective light concentration. The low-reabsorbing nature of the PIM-1/LR305 composite allowed for efficient energy transport, which is essential for optimizing LSC performance.
Practical Applications in Renewable Energy
This research offers insights for improving solar technologies. Integrating LSCs into architectural designs could help create energy-efficient buildings that generate solar power without altering aesthetics. The flexible synthesis of PIM-1 allows for adjustments to its optical properties, making it possible to design materials that absorb a broader range of the solar spectrum.
Simulations showed that scaling up LSC prototypes could improve performance, with larger devices achieving greater energy concentration. These findings suggest that further refinement of PIM-based materials could enhance efficiency and better compatibility with luminescent emitters.
Future research should focus on optimizing PIM-1 composites to expand their absorption range, particularly in the ultraviolet (UV) and near-infrared (IR) regions, while reducing light scattering and reabsorption losses. Integrating PIM-1 with other materials could lead to multifunctional energy devices. Overcoming these challenges will support the development of more efficient and adaptable solar energy solutions.
Journal Reference
Wang, Y., et al. (2025). Polymer of Intrinsic Microporosity as Light Absorber for Luminescent Solar Concentrators. Advanced Optical Materials. DOI: 10.1002/adom.202402598, https://advanced.onlinelibrary.wiley.com/doi/full/10.1002/adom.202402598
