Dec 20 2013
Researchers have used new techniques and one of the brightest X-ray sources on the planet to map the 3-D structure of an important cellular gatekeeper in a more natural state than possible before.
The new study illustrated an innovative technique to find structural details about G protein-coupled receptors (GPCRs), which are targeted by approximately 40 percent of modern medicines. This illustration represents a migraine, overlaid with a rendering of the human serotonin receptor (a GPCR) bound to ergotamine, an anti-migraine drug. Also shown is a rendering of a neuron network. Image by Katya Kadyshevskaya, The Scripps Research Institute.
The new approach, published December 20, 2013, in the journal Science, is a major advance in exploring G protein-coupled receptors (GPCRs)—a vast, hard-to-study family of proteins that play a key role in human health. GPCRs are targeted by an estimated 40 percent of modern medicines.
"For the first time we have a room-temperature, high-resolution structure of one of the most difficult-to-study but medically important families of membrane proteins," said Vadim Cherezov, a structural biologist at The Scripps Research Institute (TSRI) who led the research. "And we have validated this new method so that it can be confidently used for solving new structures."
Significant Advantages
In the study, the scientists examined the human serotonin receptor, which plays a role in learning, mood and sleep and is the target of drugs that combat obesity, depression and migraines. The scientists prepared crystallized samples of the receptor in a fatty gel that mimics its environment in the cell.
Working at the Linac Coherent Light Source (LCLS) X-ray laser at the Department of Energy's (DOE's) SLAC National Accelerator Laboratory, the scientists then used a newly designed injection system, engineered by a team from Arizona State University, to stream the gel into the path of the X-ray pulses, which hit the crystals and produced patterns used to reconstruct a high-resolution, 3-D model of the receptor.
The method eliminates one of the biggest hurdles in the study of GPCRs. It is notoriously difficult to grow sufficiently large crystals of these proteins needed for conventional X-ray studies at synchrotrons. Because LCLS is a billion times brighter than synchrotrons and produces ultrafast snapshots, it enables researchers to use tiny crystals and collect data in the instant before any damage sets in.
"This is one of the niches that LCLS is perfect for," said SLAC Staff Scientist Sébastien Boutet, a co-author of the report. "With really challenging proteins like this you often need years to develop crystals that are large enough to study at synchrotron X-ray facilities."
Wei Liu, a TSRI staff scientist who was first author of the study, said, "It's a big advantage that you don't have to harvest individual crystals—you can just load the whole gel-like sample with embedded microcrystals in the injector and start collecting data. It's also significant that the crystals don't have to be cryo-cooled in liquid nitrogen to protect them from radiation damage. Instead of looking at the samples at minus 173 degrees Celsius, we can look at them at room temperature—much closer to the temperature of their natural environment, which is body temperature."
While a team led by Scripps Research Institute scientists had previously determined the human serotonin structure with conventional methods, that effort required the receptor to be frozen. It also took much longer.
Even after samples of a GPCR are crystallized and imaged, with conventional methods it can take several months to optimize the crystal size and collect enough synchrotron X-ray data to produce structural information, Cherezov noted. This new method can potentially condense that timeline to a matter of days.
'Just the Beginning'
Disorders linked to GPCRs include hypertension, asthma, schizophrenia and Parkinson's disease. Because of their vital role in regulating cells' signaling and response mechanisms and their importance to human health, advances in receptor-related research garnered the 2012 Nobel Prize in Chemistry.
So far, scientists have been able to map the structures of fewer than two dozen of the estimated 800 GPCRs in humans. The more accurate the structure, the better scientists can use it to create effective drug treatments without side effects.
"I view these recent experiments as just the beginning," Cherezov said. "Now it is time to start making a serious impact on the field of structural biology of G protein-coupled receptors and other challenging membrane proteins and complexes. The pace of structural studies in this field is breathtaking, and there is still a lot unknown."
