In a recent article published in Scientific Reports, researchers used a multimodal imaging approach to study type I collagen 3D cell culture models, focusing on interactions between human dermal fibroblasts (HDFs) and the extracellular matrix (ECM). By combining structural, morphological, and biochemical imaging techniques, the study offers new insights into cellular behavior within 3D scaffolds.
Image Credit: Konstantin Kolosov/Shutterstock.com
Advancements in 3D Cell Culture
The importance of 3D cell culture systems in biological research cannot be overstated. Traditional two-dimensional (2D) cultures often fail to replicate the complex in vivo environments that cells experience within living organisms.
As a result, 3D cultures have become essential in tissue engineering, regenerative medicine, and drug discovery. They provide a more accurate representation of cellular interactions and enable studies of cell differentiation, migration, and therapeutic responses.
Collagen, the most abundant protein in mammals, is a key component of the ECM, playing a key role in maintaining tissue structure and function. Type I collagen scaffolds are mainly valuable due to their biocompatibility and ability to support fibroblast attachment and growth.
Recent advances in biological imaging have made it possible to characterize these systems in unprecedented detail, offering deeper insight into the spatial and molecular dynamics of the 3D cellular microenvironment.
About this Research: Using Imaging Techniques
In this paper, the authors used a multimodal imaging workflow to investigate the physicochemical properties of HDFs embedded in a type I collagen scaffold.
They integrated advanced imaging techniques, including fluorescence microscopy, second harmonic generation (SHG) microscopy, stimulated Raman scattering (SRS), secondary ion mass spectrometry (SIMS), and transmission electron microscopy (TEM). These complementary modalities provided a multidimensional view of the 3D cell culture system, enabling detailed visualization of cellular structures and their interactions with the ECM.
To ensure precise data integration, the researchers developed a robust imaging protocol that facilitated the registration of common regions of interest (ROIs) across different techniques. HDF-seeded scaffolds were prepared on gridded coverslips, allowing for accurate alignment between imaging modalities. Imaging accuracy was quantified using a target registration error (TRE) measure, which averaged approximately 250 nm.
Additionally, resin embedding, curing, and staining enabled further analysis using Time of Flight (ToF) and Nano SIMS, enhancing the characterization of both cellular and ECM components. Advanced image processing tools were utilized to refine data interpretation, facilitating the identification of molecular fragments associated with cells and the ECM.
Outcomes of Using Multimodal Analysis Workflow
The study provided key insights into the behavior of HDFs within a 3D collagen scaffold. Multimodal imaging showed that HDFs exhibited a multipolar morphology characterized by a compact cell body and extensive dendritic projections.
SHG microscopy detected significant variations in collagen density across the scaffold, which influenced fibroblast distribution and organization. Cells near the coverslip-scaffold interface displayed a spread 2D morphology. Those deeper within the scaffold assumed a compact shape with fewer projections, highlighting the impact of spatial positioning within the 3D matrix.
Quantitative analysis indicated that regions with higher collagen density exhibited increased SHG signal intensity, forming a dense network that restricted cell bodies while promoting dendritic projections. SIMS imaging identified molecular fragments associated with cellular components and the ECM.
By integrating multiple imaging modalities, the authors comprehensively assessed spatial heterogeneity and biochemical interactions within the 3D culture system. Correlating optical and mass spectrometry data bridged structural and molecular insights, deepening the understanding of cell-ECM interactions.
These findings highlight the importance of multimodal imaging in tissue engineering, providing a robust framework for optimizing scaffold designs to influence cellular behavior.
Potential Applications in Biomedical Research
This research has significant implications for tissue engineering, regenerative medicine, and drug development. By advancing the understanding of cell-ECM interactions, it supports the development of tissue scaffolds that more accurately mimic native tissues.
The introduced workflow can also be applied to assess the effects of therapeutic agents on cellular behavior within 3D cultures, providing a physiologically relevant approach for preclinical drug testing.
The ability to visualize and analyze complex cell-microenvironment interactions can enhance personalized medicine, enabling treatments tailored to individual cellular responses. The demonstrated multimodal imaging approach has potential applications in cancer research, developmental biology, and biomaterials science.
Future work should focus on optimizing imaging techniques, particularly improving subcellular resolution and integrating live-cell imaging to capture dynamic processes in real time.
Investigating the effects of different biomaterials and ECM compositions will be essential for developing innovative therapeutic approaches. Combining advanced imaging with computational modeling may further enhance the understanding of cellular interactions within 3D cultures, leading to improved tissue regeneration and repair strategies.
As 3D cell culture technologies evolve, approaches like this one provide a robust foundation for driving innovation across the life sciences and transforming the future of biomedical research.
Journal Reference
Dondi, C., et al. (2025). Multiparametric physicochemical analysis of a type 1 collagen 3D cell culture model using light and electron microscopy and mass spectrometry imaging. Sci Rep. DOI: 10.1038/s41598-025-93700-3, https://www.nature.com/articles/s41598-025-93700-3
