X-ray fluorescence (XRF) has become an invaluable analytical technique for non-destructively authenticating precious metal artifacts and artworks through elemental analysis, empowering art historians and archaeologists to accurately date items, determine origins, reveal hidden drafts, and distinguish forgeries from antiquities.
Image Credit: Mariana_Rusanovschi/Shutterstock.com
What is XRF, and How is it Employed in Art and Archeology?
XRF is an analytical method that determines the elemental composition of materials by irradiating them with high-energy X-rays and analyzing the unique secondary (fluorescent) X-rays emitted in response from the atoms within.
An XRF instrument consists of an X-ray source, filters, collimators, sample chamber, detector, and data analysis hardware/software. The source emits primary X-rays that bombard the sample, inducing the photoelectric effect and ejecting inner shell electrons from atoms.
Electrons in higher orbitals then drop into the vacancies, releasing energy equal to the specific difference in orbital transitions. These secondary or fluorescent X-ray emissions are unique to each element since orbital electron energies differ between elements. The detector measures the wavelengths and intensities of these fluorescent X-rays, which the software interprets to yield elemental composition.
These unique spectral fingerprints also provide insights into the sample's age, origins, and authenticity by determining relative element abundances. For example, bronze alloys show diverse copper, tin, and trace element ratios across civilizations, while an artifact's corrosion layers, surface patinas, and minor constituents aid in verifying timelines and excluding modern tampering.
Lastly, XRF's non-destructive nature has made it invaluable for examining priceless relics, as it eliminates the need for sampling compared to traditional analytical chemistry techniques.
Applications in Archaeology and Art Analysis
XRF first revolutionized archaeology in the 1960s by enabling rapid in-situ sourcing of obsidian and ceramics at excavation sites to determine artifact origins and trade routes. It became invaluable for studying flow, exchange, cultural contacts, and migration patterns in the Americas, Near East, and Old World.
The 21st century has witnessed ever-expanding applications in art, sculpture, and archaeology as portable XRF systems have continued to advance in precision, mobility, automation, and user-friendliness.
Tracing the Origins of Ancient Artifacts
XRF analysis has been pivotal in uncovering the geographical sources and origins of ancient artifacts. For example, it traced the Nebra Sky Disk to ancient German mining sites based on its bronze composition and matched Etruscan mirrors to distinct Italian workshops, using trace elements to understand trade routes.
XRF also identified material differences among Terracotta Army warrior sculptures, linking them to various production centers. It even deciphered the complex synthesis of Maya blue pigment and connected the elemental makeup to specific trade networks for supplying the raw materials.
Exposing Artistic Forgeries
XRF's elemental fingerprinting is invaluable in swiftly authenticating metal antiquities and addressing art forgery through detailed elemental analysis.
For example, XRF exposed fraudulent Dead Sea Scroll fragments by detecting modern ink, confirmed a suspected ancient Egyptian limestone princess sculpture as fake through the identification of modern pigments, and ruled a contested Caravaggio painting, "Supper at Emmaus" as an imitation by revealing non-standard elements.
Coin Metallurgy and Numismatic Insights
XRF is commonly used for bulk coin analysis, determining metal purity, verifying minting origin and date, and revealing the evolution of metallurgical impurities and production methods over time.
Bruker's M4 TORNADO micro-XRF uncovered a highly pure silver coating on a coin, covering an inner copper-rich layer, suggesting silver leaching from the core over 2000+ years, with ~35% interior silver content consistent with historical Roman coinage, demonstrating surface enrichment due to burial conditions.
Zinc Mapping Reveals Hidden Preliminary Sketches in Leonardo's Painting
Beneath the final layers of Leonardo da Vinci's immortal "Virgin of the Rocks", Bruker's M6 JETSTREAM micro-XRF scanner uncovered remnants of an earlier abandoned composition using scanning x-ray fluorescence element mapping. Zinc traces revealed a major repositioning of figures and relationships predating the final rendering.
The ultimate revelation or practical challenges that triggered such a drastic shift in approach will remain a mystery. Yet being able to digitally reconstruct and compare this hidden first draft to a renowned finished product provides rare scholarly insight into the intersections of mind, method and manifestation within an evolving masterpiece.
XRF Reveals Ancient Egyptian Art Evolution
A recent study published in PLOS One used portable X-ray fluorescence imaging to unveil hidden alterations in ancient Egyptian artworks, revealing changes in arm position, sceptre, necklace, and headdress in paintings at the tomb chapels of Menna and Nakhtamun.
Researchers used lightweight, battery-operated instruments to analyze elemental markers in pigments, mapping faded or covered paint. The discoveries suggest potential links to shifts in symbolic meanings, initial drafts, or aesthetic corrections in these 3000-year-old artworks along the Nile River.
The Future of XRF in Art and Archaeology
From verifying antiques to revealing historical prints and forgeries, XRF empowers cultural understanding and art authentication, promising even greater accessibility and performance in the 21st century. This versatile technique serves as a timeless tool for professionals studying artifacts across eras, connecting humanity through elemental science and masterful artistry, unveiling the human saga.Top of Form
Ongoing advances in portable XRF technology, with improvements in detection limits, precision, automation features, and user-friendliness, will expand its capabilities and widespread adoption.
More from AZoOptics: Interferometric Techniques for Surface Profiling and Metrology
References and Further Reading
Analytical Sciences Digital Library. (2023). Metals Analysis by X-ray Fluorescence. [Online]. Available at: https://chem.libretexts.org/Bookshelves/Analytical_Chemistry/Supplemental_Modules_(Analytical_Chemistry)/Analytical_Sciences_Digital_Library/
Analytical Methods Committee Technical Briefs. (2021). Hand-held X-ray fluorescence analysis of archaeological artefacts: challenges, advantages and limitations. Analytical Methods, 13(33), 3731-3734. https://doi.org/10.1039/D1AY90094C
Shackley, M. S. (2011). An introduction to X-ray fluorescence (XRF) analysis in archaeology. X-ray fluorescence spectrometry (XRF) in geoarchaeology, 7-44. https://doi.org/10.1007/978-1-4419-6886-9_2
Elvatech. (2023). How XRF analysis reveals the origins of ancient artifacts and artworks. [Online]. Available at: https://elvatech.com/how-xrf-analysis-reveals-the-origins-of-ancient-artifacts-and-artworks/
Bruker. (2023). Dating Roman Silver Coins: Getting to the True Composition. [Online]. Available at: https://www.bruker.com/en/applications/academia-materials-science/art-conservation-archaeology/archaeology-and-archaeometry/dating-roman-silver-coins--getting-to-the-true-composition.html
Bruker. (2023). Evolution of a Masterpiece. [Online]. Available at: https://www.bruker.com/en/applications/academia-materials-science/art-conservation-archaeology/fine-art-analysis/evolution-of-a-masterpiece.html
Martinez, P., Alfeld, M., Defeyt, C., Elleithy, H., Glanville, H., Hartwig, M., ... & Walter, P. (2023). Hidden mysteries in ancient Egyptian paintings from the Theban Necropolis observed by in-situ XRF mapping. Plos one, 18(7), e0287647. https://doi.org/10.1371/journal.pone.028764
