Revolutionizing Silicon Photonics: GeSn-Based Continuous-Wave Lasers

An article recently published in Nature Communications discussed advancements in silicon-based photonic integrated circuits (PICs) by developing a continuous-wave (CW) electrically pumped multi-quantum-well laser using group-IV semiconductors. The aim was to enhance integrated photonics, particularly for applications requiring efficient light sources.

Close-up of a microscope focusing on a microchip with red laser light illuminating the surface. The image shows intricate details of a circuit board with components and glowing red lights.

Image Credit: Inlined/Image Credit

The researchers addressed the challenges of integrating laser sources into silicon PICs, a technology expected to impact information and communication systems. Their work represents progress toward incorporating laser sources into silicon photonic systems, which are essential for quantum computing, telecommunications, and sensing applications.

Advancements in Silicon-Based Photonic Technology

Silicon-based PICs have become an important technology for information and communication systems. Their ability to integrate optically active components on silicon chips offers advantages such as high optical performance, flexibility, and cost-efficiency, driving advancements in applications like data communication and environmental sensing.

Silicon photonics (SiPh) technology has enabled the development of various active and passive components for diverse uses, including cryogenic applications in integrated quantum technologies and optical computing.

Despite significant progress, fabricating efficient, electrically pumped light sources using only group-IV semiconductors remains challenging. Existing techniques, such as bonding or microprinting III-V lasers onto silicon, face limitations in scalability and integration. Developing Group-IV semiconductor lasers, particularly those based on germanium-tin (GeSn) and silicon-germanium-tin (SiGeSn), has the potential to simplify integration and enable further miniaturization.

About the Research: Fabrication and Evaluation

The authors focused on fabricating GeSn/SiGeSn multiple-quantum-well (MQW) laser for cryogenic operation, specifically within the temperature range of 4 to 77 K. Their goal was to achieve CW operation and low current injection thresholds, which are important for use in quantum computing and advanced technologies.

The laser heterostructure was constructed using reduced-pressure chemical vapor deposition (RP-CVD) on a 200-mm silicon wafer. A 2.5-µm-thick Ge virtual substrate was used to grow a partially relaxed 200-nm Ge0.9Sn0.1 buffer layer. This buffer created a larger in-plane lattice constant, enabling the integration of the optically active MQW stack. The MQW structure comprised alternating layers of Si0.06Ge0.83Sn0.11 barriers and Ge0.885Sn0.115 wells, designed to improve carrier confinement and optical gain.

The laser cavity was constructed as an under-etched microdisk, which enhanced light confinement and supported whispering gallery modes (WGMs). The fabrication process utilized complementary metal-oxide-semiconductor (CMOS)-compatible techniques, ensuring the potential for large-scale integration with existing silicon photonic platforms.

Advanced characterization methods, including scanning transmission electron microscopy (STEM) and energy-dispersive X-ray mapping, were used to assess the quality of the epitaxial layers and the distribution of elements within the heterostructure.

Key Findings and Insights

The study demonstrated the successful realization of CW lasing in GeSn/SiGeSn MQW disk lasers at low temperatures. The laser achieved a threshold current density of 6.2 kA/cm² at 5 K, significantly lower than previous designs. It operated continuously at injection currents as low as 4 mA, indicating its potential for integration into photonic systems. Current-voltage characteristics showed clear rectifying behavior across a temperature range of 10 K to 100 K.

The optical emission from the microdisk laser transitioned from spontaneous to stimulated emission as the injection current increased. A sharp laser line at 0.535 eV (2.319 μm) with a linewidth of 50 μeV was observed at an injection current of 6 kA/cm². These outcomes showed the robustness of the device, which maintained lasing across varying temperatures and injection conditions. Additionally, thermal analysis indicated that self-heating effects became prominent at higher current densities, impacting overall performance.

Furthermore, the authors explored the laser's behavior under pulsed pumping conditions. Quasi-continuous-wave (QCW) operation improved heat dissipation, allowing the laser to maintain performance at higher temperatures. This capability expands its potential applications in various settings.

Practical Applications

This research has significant implications for the future of silicon photonics. Integrating GeSn-based lasers into silicon photonic circuits could advance communication systems, particularly in quantum computing and high-speed data transmission. Their ability to operate at cryogenic temperatures makes them ideal for quantum technologies, where precise optical signal control is crucial. Efficient, electrically pumped lasers integrated into silicon photonic platforms open new possibilities for quantum computing hardware, neuromorphic systems, and advanced communication networks.

Additionally, the compatibility of these devices with existing CMOS technology offers a pathway for large-scale integration of photonic components, essential for the next generation of information technology. The findings also highlight the potential for developing compact, efficient sensors for environmental monitoring and biomedical applications. The unique properties of GeSn and SiGeSn materials enable enhanced detection in the mid-infrared range, benefiting molecular sensing and imaging applications.

Future Directions

This study presents progress in developing Group-IV semiconductor lasers, particularly for cryogenic applications. The successful demonstration of CW operation at low current densities provides a foundation for further research in silicon photonics.

Future work should focus on optimizing heterostructure designs, exploring alternative materials, and improving thermal management to enhance performance at higher temperatures. Integrating these lasers into silicon-based platforms could expand the potential of photonics in both classical and quantum computing.

Journal Reference

Seidel, L., Liu, T., Concepción, O. et al. (2024). Continuous-wave electrically pumped multi-quantum-well laser based on group-IV semiconductors. Nat Commun. DOI: 10.1038/s41467-024-54873-z, https://www.nature.com/articles/s41467-024-54873-z
