In a recent Light | Science & Applications article, researchers explored using nonlinear metasurfaces to enhance broadband infrared imaging of arbitrary objects.
Image Credit: mechichi/Shutterstock.com
They introduced an innovative framework that used guided-mode resonance in dielectric metasurfaces to improve signal conversion via four-wave mixing (FWM). The aim was to overcome the narrow operational bandwidths of traditional nonlinear metasurfaces, thereby enhancing infrared imaging and spectroscopy applications.
Advancement in Nonlinear Metasurfaces
Nonlinear metasurfaces have attracted considerable attention due to their potential in imaging, quantum computing, and optical sensing. Traditional nonlinear platforms, like crystals and fibers, are limited by phase matching and high power requirements. In contrast, metasurfaces, composed of subwavelength resonant structures, offer a compact and efficient way to enhance light-matter interactions.
Advancements in dielectric metasurfaces have enabled improved control over amplitude, phase, and direction of emitted light, which is vital in applications like holography and image encoding. However, low conversion efficiencies and limited bandwidths have restricted broader application. This study addresses these limitations using guided-mode resonance to expand nonlinear imaging bandwidth.
Proposed Imaging Framework
The authors proposed a novel nonlinear imaging platform that enhances signal conversion via FWM with a pump beam. This approach employs metasurfaces resonant at the pump wavelength rather than at the signal or nonlinear emission wavelengths, enabling broadband nonlinear imaging of diverse objects.
They designed a silicon disk-on-slab metasurface with an excited guided-mode resonance at the pump wavelength. This enabled the direct conversion of an infrared spectrum, from 1000 to 4000 nm, into visible light. Through FWM, the approach reduced high-power signal requirements, leveraging the quadratic relationship between pump intensity and conversion efficiency.
Numerical simulations in COMSOL Multiphysics and experimental validation analyzed the metasurface’s field patterns, transmittance spectra, and multipolar characteristics.
Key Findings and Insights
The silicon metasurface achieved broadband nonlinear imaging via FWM. Fixing the pump wavelength at a resonant mode and adjusting the signal wavelength produced strong FWM emissions across a broad range, significantly enhancing nonlinear emission and reducing high-power signal requirements. The researchers measured angle-dependent transmission spectra and observed topological resonance splitting of guided-mode resonances.
The team also analyzed the metasurface’s band structure, identifying four guided modes (M1, M2, M3, and M4) and their coupling regions. They performed spherical multipolar analysis to understand the behaviors of these resonances, including the electric dipole (ED) and magnetic dipole (MD) contributions.
The experimental setup used a custom nonlinear optical system with femtosecond laser beams for pump and signal inputs. Converted images were captured through a CCD camera and spectrometer for detailed emission analysis.
Additionally, the polarization sensitivity of FWM emissions allowed the authors to control emission behavior, making the technique selectively responsive to polarization. They also demonstrated that the metasurface could detect sample thickness based on the time delays of two pulsed lasers, highlighting its potential for non-invasive sensing and imaging.
Applications
This research has significant implications for next-generation all-optical infrared imaging. The proposed FWM-based technique offers high conversion efficiency, opening new possibilities in sensing, night vision, and spectroscopy. Converting infrared images into visible light supports the development of compact, ultrathin photonic devices.
The polarization-sensitive FWM emission enhances resolution and sensitivity in surface detection and material characterization. Additionally, the non-invasive ability to detect object thickness has applications in fields like art conservation and biological imaging. This approach is also valuable for imaging through opaque materials, with potential applications in medical imaging, security, and environmental monitoring.
Discussion: Future Outlooks
This platform demonstrated robust broadband infrared imaging by leveraging guided-mode resonance in dielectric metasurfaces. Using a pump beam resonant at the guided mode, the team significantly enhanced signal conversion efficiency through FWM, overcoming the narrow operational bandwidth typical of nonlinear metasurfaces. This advancement lays the groundwork for next-generation infrared imaging techniques and compact photonic devices with diverse applications.
Future research should focus on optimizing metasurface designs to further improve conversion efficiencies and broaden operational bandwidths. Integrating this technology into practical systems will be essential for applications in medical diagnostics, environmental monitoring, and security imaging. Further advancements in materials and fabrication could enhance scalability, advancing next-generation infrared imaging devices.
More from AZoOptics: Optical Metasurfaces: Applications in Imaging and Sensing
Journal Reference
Zheng, Z., et al. (2024). Broadband infrared imaging governed by guided-mode resonance in dielectric metasurfaces. Light Sci Appl. DOI: 10.1038/s41377-024-01535-w, https://www.nature.com/articles/s41377-024-01535-w
